2018 JAYCO JAY FLIGHT 28RLS

2018 Jayco Jay Flight 28RLS is a popular rear-living travel trailer designed primarily for couples, though it can sleep up to 6 people. Its layout features a single large slide-out that significantly opens up the living and dining areas.

Floorplan Highlights

• Rear Living Area: Features two recliners at the very back under a large panoramic window, a pull-down J-Steel jackknife sofa, and a booth dinette for additional seating and sleeping space.
• Dual Entry Doors: Includes a main entry door into the living area and a private secondary entry directly into the front master bedroom.
• Center Kitchen: Equipped with an 8-cubic-foot refrigerator, a three-burner range with a stainless oven, a microwave, and a large 60/40 kitchen sink with a pull-out sprayer.
• Front Master Bedroom: Contains a queen Simmons mattress with under-bed storage struts and overhead cabinets.
• Walk-Through Bathroom: Features a radius glass shower with a skylight, a porcelain foot-flush toilet, and a vanity with storage.

• Dimensions: The unit measures 32' 5" in length, 8' in width, and 11' in height (including the standard A/C unit).
• Weight & Towing: It has an Unloaded Vehicle Weight (UVW) of 6,390 lbs, a Hitch Weight of 700 lbs, and a GVWR of 8,800 lbs, allowing for a cargo carrying capacity of 2,410 lbs.
• Capacities: Holding tanks include 76 gallons for Fresh Water, 39 gallons for Gray Water, and 39 gallons for Black Water. It also carries 60 lbs of Propane (two 30 lb bottles).
• Sleeping & Seating: The layout sleeps up to 4-6 people, featuring a private front bedroom with a Queen Simmons mattress and a rear living area with a J-Steel jackknife sofa and booth dinette.

• Climate Control: Standard 13,500 BTU roof-mounted A/C and a thermal package with a heated and enclosed underbelly.
• Appliances: A residential-style kitchen with an 8 cu. ft. refrigerator, 3-burner range with "SuperBurner," and a stainless steel microwave and oven.
• Exterior: Includes an 18-foot power awning with LED lighting and integrated speakers, a power tongue jack, and Goodyear Endurance tires.
• Entertainment: AM/FM/CD/DVD player with MP3, Bluetooth, and HDMI connectivity, typically paired with a 32-inch LED TV.
